OWON Digital Oscilloscope 4 CH
35000 INR/Piece
Product Details:
- Layer Single main PCB, multi-layer internal construction
- Surface Treatment Smooth plastic, anodized metallic connectors
- Size 320 x 150 x 120 mm (Approx.)
- Feature 4 Channels, large color LCD, compact design, portable
- Installation Guideline Desktop mounting, standard AC connection
- Product Type Digital Oscilloscope
- Material High-quality plastic and metal assemblies
- Click to View more
X
OWON Digital Oscilloscope 4 CH Price And Quantity
- 1 Piece
- 35000 INR/Piece
OWON Digital Oscilloscope 4 CH Product Specifications
- Oscilloscope for electronics testing and measurement
- White/Grey with blue side panels
- Single main PCB, multi-layer internal construction
- 320 x 150 x 120 mm (Approx.)
- Smooth plastic, anodized metallic connectors
- 80-250V AC
- Digital Oscilloscope
- High-quality plastic and metal assemblies
- Desktop mounting, standard AC connection
- 4 Channels, large color LCD, compact design, portable
- 320 mm (approx.)
- 40C (operating)
OWON Digital Oscilloscope 4 CH Trade Information
- Delhi
- Cash in Advance (CID)
- 10 Piece Per Month
- 7 Days
- Contact us for information regarding our sample policy
- Asia
- All India
Product Description
OWON Digital Oscilloscope 4 CH is a high-performance test instrument that is commonly used to precisely analyze electronic signals at variable voltages and time settings. It is fabricated by using premium-class components that provide results in waveforms. The calibrated system of this unit ensures high accuracy and precision at variable power levels. The visual output provided by this machine helps users to analyze and troubleshoot various types of electronic circuits. OWON Digital Oscilloscope 4 CH also helps to examine the behavior of signal against time for the identification of glitches and noise.
High-Performance Multi-Channel Measurement
Empowering engineers and technicians, the OWON Digital Oscilloscope offers four independent input channels, each boasting a 100 MHz bandwidth and real-time data acquisition at 1 GS/s. This configuration supports complex diagnostics and signal comparisons crucial for electronic circuit analysis.
Vivid Display and User-Friendly Design
The large, 8-inch TFT color LCD ensures easy visualization of intricate waveforms and parameters. Its smooth plastic surface and anodized connectors provide a sleek look while ensuring reliability and durability in diverse environments.
Convenient Connectivity and Storage
With versatile data ports like USB, LAN, and RS232 (model-specific), exporting captured waveforms and remote operation are streamlined. Waveform storage and recall functions allow users to revisit past measurements, supporting efficient workflow and data integrity.
FAQ's of OWON Digital Oscilloscope 4 CH:
Q: How do I install the OWON Digital Oscilloscope for desktop use?
A: Place the oscilloscope securely on a stable desktop surface and connect it to a standard AC power supply (rated 80-250V). Ensure proper grounding and use the provided probes for signal measurement. No additional mounting accessories are necessary for desktop installation.Q: What are the main benefits of using the OWON 4-channel oscilloscope in electronics measurement?
A: The device enables simultaneous monitoring of up to four signals, with high sampling rates and a clear, large display for accurate waveform analysis. Its compact size and advanced trigger options enhance productivity and flexibility in laboratory or field environments.Q: When should I utilize waveform storage and recall features?
A: Waveform storage and recall are useful during long testing processes, allowing you to save critical signal snapshots for later analysis, comparison, or documentation. This is especially valuable in troubleshooting and reporting tasks.Q: Where can the oscilloscope be used most effectively?
A: The OWON Digital Oscilloscope is ideal for electronics design labs, repair centers, educational environments, and manufacturing facilities due to its robust construction, portability, and flexible connectivity options.Q: What is the process for switching between probe attenuation settings?
A: Simply toggle the probe between 1X and 10X using the switch on the probe body. This adjustment allows you to change the measurement range and vertical sensitivity, accommodating signals of varying amplitude.Q: How does the oscilloscope's trigger system improve measurement accuracy?
A: By selecting the appropriate trigger mode (Edge, Pulse, Video, Slope, Alternate), users can stabilize and capture relevant waveform segments, reducing noise and ensuring precise signal timing analysis.Q: What humidity and temperature conditions are recommended for operating the OWON Digital Oscilloscope?
A: Operating humidity should not exceed 85% RH (non-condensing), and the maximum recommended temperature is 40C. These parameters ensure optimal performance and longevity of the instrument.Tell us about your requirement
